GT15-25 44.39/60.01mm 784369-0002 11+0Blades Point milling snake performance billet compressor wheel for 758351-0005

1. MODEL:GT15-25 Forward rotation

2.GT15-25 784369-0002/787571-0002 44.39/60.01mm 11+0 Blades point milling/snake curve high performance billet/milling compressor wheel for Audi Q7/VW Touareg/Mercedes ML350/GL350/S350 758351-0003, 758351-0005, 758351-0009, 758351-0013, 758351-0015, 758351-0017, 758351-0019, 758351-0020, 758351-0022, 758351-0024, 765985-0001, 765985-0003, 765985-0001, 765985-0003, 765985-0005, 765985-0006, 765985-0008, 765985-0010, 802774-0004, 802774-0005, 769909-0009, 769909-0010, 776470-0001, 776470-0003, 769909-0010, 776470-0001, 769909-0009

3.Size:

Nose Diameter:11.50mm

inducer:44.39mm

Exduder:60.01mm

Tapered tip exducer:64.20mm

Tip height:4.63mm

Superback:3.79mm

Overall height:32.41mm

bore size :5.08mm

bore type:through

Trailing angle:45 degree

Cutback:6.0mm

Sp hieght angle:0.00

Blade height:22.50mm

Splitter height:0.00

Forward rotation

11+0 blades

It is for OE compressor housing

Tapered tip angle: 30 degree

Application:

Audi Q7/VW Touareg/Mercedes ML350/GL350/S350

758351-0003, 758351-0005, 758351-0009, 758351-0013, 758351-0015, 758351-0017, 758351-0019, 758351-0020, 758351-0022, 758351-0024, 765985-0001, 765985-0003, 765985-0001, 765985-0003, 765985-0005, 765985-0006, 765985-0008, 765985-0010, 802774-0004, 802774-0005, 769909-0009, 769909-0010, 776470-0001, 776470-0003, 769909-0010, 776470-0001, 769909-0009

4.High quality and competitive price.

5.if you want more details, please send email to me.

We can produce as your requirement.

ALL the billet compressor wheels have been balanced.

The more models we also have.
