| Brand Name: | NO |
| Model Number: | K16 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Packaging Details: | neutral packing |
| Delivery Time: | 3-7 days |
| Payment Terms: | TT ,western union ,paypal |
| Supply Ability: | 1000 |
| Size: | 51.80/68.00mm | Type: | Turbochargers |
|---|
1.Model:K16 reverse
3.Size:
Nose diamter:11.60mm
inducer:51.80mm
Exduder:68.00mm
Tapered tip exducer:72.08mm
Tip height:4.53mm
Superback:3.81mm
Overall height:33.40mm
bore size :5.41mm
bore type:through
Trailing Angle:60 degree
Cutback:3.0mm
SP Height Angle:-4.50
Blade height:27.63mm
Splitter Height:18.20mm
6+6 blades
reverse rotation
Tapered tip angle:30 degree
It is custom size ,please check carefully before buying.
4.High quality and competitive price.
5.if you want more details, please send email to me.
We can produce as your requirement.
All the billet compressor wheels have been balanced.
