Home ProductsBillet compressor wheel

HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404

HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404

    • HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404
    • HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404
    • HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404
    • HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404
    • HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404
    • HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404
    • HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404

    Product Details:

    Brand Name: NO
    Model Number: HY55

    Payment & Shipping Terms:

    Minimum Order Quantity: 1PC
    Packaging Details: neutral packing
    Delivery Time: 3-7 days
    Payment Terms: TT ,western union ,paypal
    Supply Ability: 1000
    Contact Now
    Detailed Product Description

    1. MODEL:HY55 forward
    2.HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/4046277/4047969/4047970/4047971
    3.Size:
    Nose diameter:21.90mm
    Inducer:73.40mm
    exducer:109.00mm
    Tip height:7.83mm
    Superback:9.88mm
    bore size :8.01mm
    Overall height:54.03mm
    Trailing angle:45
    Cutback:0.0
    Splitter height:16.45mm
    SP height angle:-2.70
    Blades height:36.62mm
    8+8 blades forward
    Tapered tip angle:30 degree
    Fit for OE compressor housing
    Application:
    4046275
    4046276
    4046277
    4047969
    4047970
    4047971
    4.High quality and competitive price.
    5.if you want more details, please send email to me.

    All the compressor wheel have been balanced.
    HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404HY55 3597223 73.40/109.00mm 8+8 blades Turbo milling/aluminum 2618/billet compressor wheel IVECO for 4046275/4046276/404
