K04 5306-123-2006 44.92/56.08mm 7+7 blades turbo milling/aluminum 2618/billet compressor wheel for 5304-970-0033

Brand Name:	NO
Model Number:	K04

Contact Now

Detailed Product Description

Size:	44.92/56.08mm	Type:	Turbochargers

1. MODEL:K04 FORWARD

2.K04 44.92/56.08mm 5306-123-2006 7+7 blades turbo Billet/milling/aluminum 2618 compressor wheel for 5304-970-0033

3.Size:

Nose diameter:10.97mm

Inducer:44.92mm

exducer:56.08mm

Tapered tip exducer:60.25mm

Tip height:4.61mm

Superback:1.80mm

bore size :4.61mm

Overall height:25.68mm

Trailing Angle:65 degree

Cutback:0.0

SP Height angle:-4.00

Tapered tip Angle:30 degree

Blades height:19.59mm

Splitter height:12.80mm

7+7 blades forward

Fit for OE compressor housing

4.High quality and competitive price.

5.if you want more details, please send email to me.

All the compressor wheels have been balanced.

Skype: maxabledieselparts

Wechat/Whatsapp:+86-18018657719

K04 5306-123-2006 44.92/56.08mm 7+7 blades turbo milling/aluminum 2618/billet compressor wheel for 5304-970-0033
