Name: S3B 199097/167410/167411 6+6 blades 60.89/86.39mm turbo Billet/milling compressor wheel for 166338/166490/166497/166501
Brand: Max Able Auto Parts Co.,Ltd.
SKU: S3B
Price: Negotiable USD
Availability: InStock

Home Products Billet compressor wheel

S3B 199097/167410/167411 6+6 blades 60.89/86.39mm turbo Billet/milling compressor wheel for 166338/166490/166497/166501

Product Details:

Brand Name:	NO
Model Number:	S3B

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Packaging Details:	neutral packing
Delivery Time:	3-7 days
Payment Terms:	TT ,western union ,paypal
Supply Ability:	1000pcs

Contact Now

Detailed Product Description

1. MODEL:S3B forward

2.S3B 199097/167410/167411 6+6 blades 60.89/86.39mm turbo Billet/milling/aluminum 2024 compressor wheel for 166338/166490/166497/166501/166789/166822/166893/166925/167164/167166/167167

3.Size:

Nose diameter:17.69mm

Inducer:60.89mm

exducer:86.39mm

Tip height:8.92mm

Superback:8.92mm

bore size :7.94mm

Overall height:46.79mm

Blade height:32.56mm

Cutback:0.0

Trailing Angle:75-90

Fit for OE compressor housing
